Model 19052

The Guardian 19052 can conduct AC/DC/IR Hipot testing and measurements of insulation resistance (IR). Front panel operation, digital display, and user-friendly controls allow test parameters and limits to be set easily without high-voltage activation. AC 5kV and DC 6kV output. 1kV insulation resistance test. Insulation resistance measurement: 1Ω~10Ω. 2-Year factory warranty. This model replaced Quadtech's Guardian 1030.

• AC/DC/IR 3 in 1 hipot tester
• AC 5kV and DC 6kV output
• 1kV insulation resistance test
• Insulation resistance measurement: 1Ω~10Ω
• Ground continuity check
• Open Short Check(OSC) function
• GFI shutdown the instrument when the imbalance current > 0.5mA
• Flashover (ARC) detection
• Quick discharge of DUT in IR and DC test
• Pause mode
• Large LCD display
• UL and TUV approved
• CE mark
• Programmable ramp/fall and test time
• Programmable high/low limit
• Save/Recall program test function
• Remote control and interface support
• 2-Year factory warranty
