19052 Guardian Hipot Tester (AC/DC/IR)

19052 Guardian Hipot Tester (AC/DC/IR)

Model 19052

We currently have 43 in stock ✔.

Model 19052

The Guardian 19052 can conduct AC/DC/IR Hipot testing and measurements of insulation resistance (IR). Front panel operation, digital display, and user-friendly controls allow test parameters and limits to be set easily without high-voltage activation. AC 5kV and DC 6kV output. 1kV insulation resistance test. Insulation resistance measurement: 1Ω~10Ω. 2-Year factory warranty. This model replaced Quadtech's Guardian 1030.

  • AC/DC/IR 3 in 1 hipot tester
  • AC 5kV and DC 6kV output
  • 1kV insulation resistance test
  • Insulation resistance measurement: 1Ω~10Ω
  • Ground continuity check
  • Open Short Check(OSC) function
  • GFI shutdown the instrument when the imbalance current > 0.5mA
  • Flashover (ARC) detection
  • Quick discharge of DUT in IR and DC test
  • Pause mode
  • Large LCD display
  • UL and TUV approved
  • CE mark
  • Programmable ramp/fall and test time
  • Programmable high/low limit
  • Save/Recall program test function
  • Remote control and interface support
  • 2-Year factory warranty
